Hail the first sound ‘lasers’
Feb 25, 2010 5 comments
Two independent groups of physicists have unveiled the first phonon "lasers" – devices that emit coherent sound waves in much the same ways as lasers emit coherent light waves. Sometimes called "sasers", one of the devices emits sound at about 400 GHz while the other operates in the megahertz range.
Such very high frequency sound could be used to probe the interiors of tiny objects – and the ability to create laser-like beams of sound could lead to new imaging applications. Indeed, the differences between the two devices suggest that sasers could be made to operate over a wide range of frequencies.
At the heart of any optical laser is a medium with an electronic transition that involves the emission of a photon. The medium is "pumped" by an external energy source so that the majority of the electrons are in the higher energy state of the transition. When such a state decays, it emits a photon that can stimulate the emission of many more photons – which in turn stimulate further emission. Because they are all produced by the same quantum process, the photons emerge as a coherent beam of light.
Spontaneous emission problems
Just as light behaves as both particle and wave, so sound can be described in terms of particles called phonons – quanta of vibrational energy that behave in much the same way as photons. While there is no reason why stimulated emission shouldn't also work for phonons, physicists had struggled to find materials in which stimulated emission – rather than random spontaneous emission – is the dominant decay process.
Now, two independent groups have come up with two very different solutions to this problem.
At the University of Nottingham in the UK, Tony Kent and colleagues have made a saser that operates at about 440 GHz. Their device comprises alternating layers of the semiconductor gallium arsenide (GaAs) and the insulator aluminium arsenide (AlAs). The GaAs layers act as quantum wells, which can trap electrons. If an electrical bias is placed across the layers, the electrons are inclined to hop across an AlAs barrier into the next well – emitting a phonon in the process. Crucially, such a hop can be stimulated by a similar phonon. To ensure that the phonons bounce back and forth through the structure like photons in a laser cavity, the team set the distance between the repeating layers to resonate with the wavelength of the phonons.
The team tested the device by firing a femtosecond laser pulse at one end of the layered structure. This creates phonons that initiate the stimulated emission. A second laser pulse is then bounced off the device to measure the reflectance of the material over several hundred picoseconds. Kent and colleagues observed oscillations in the reflectance that are caused by coherent phonons.
As the team increased the bias voltage from 80–180 mV, it saw an increase in the amplitude of the coherent phonons that peaked at about 160 mV before falling at higher voltages. According to Kent, the peak occurs when the phonon wavelength resonates with the device.
Pair of resonators
Meanwhile at the California Institute of Technology (Caltech), Ivan Grudinin and colleagues use two microwave resonators – each about 6 µm in diameter and made of silica – to create the phonon-producing transition for their saser. The resonators are separated by a gap of about 1 µm, which is small enough for the devices to be coupled via light waves to form a two-state quantum system.
A laser is used to pump the system to the higher energy state. Phonons at megahertz frequencies are emitted, stimulating the further emission of phonons. The team confirmed that the system was indeed a phonon laser by turning up the pumping power and observing no sound emission until a threshold level – above which the power increased rapidly and sound was emitted in a very narrow frequency range.
Kent told physicsworld.com that the two approaches are complementary and it should be possible to use one device or the other to create coherent phonons at any frequency in the megahertz to terahertz range.
A terahertz saser would be particularly useful in nanotechnology because its phonons would have a wavelength of about one nanometre and could penetrate relatively deep into a solid structure – opening the door to 3D imaging of nanostructures. This is unlike current analysis techniques such as electron microscopy, which are limited to surface analysis.
Sasers could also be used to cause the periodic strain of a material – modulating its optical or electrical properties. This could be used to create very fast switches or to generate terahertz electromagnetic radiation – something that is currently difficult to do.
"The next step is to optimize the device to increase the coherent acoustic output and minimize the background from spontaneous emission," said Kent. "We are also working on devices that can be integrated with a saser to make a kind of acoustic lab on a chip to measure nanostructures."
