Nanowires line up for plastic electronics
Sep 18, 2003
Scientists from Nanosys in the US have used semiconductor nanowires and nanoribbons to make thin-film transistors with good electrical performance. By separating the growth of the nanowires and ribbons from the substrate-coating process, the team was able to apply the nanomaterials at room temperature to both silicon and plastic substrates. The technology could find use in a broad range of applications in macroelectronics such as flat-panel displays and radio-frequency communications. It could also be used in disposable computing and storage electronics, and for ‘smart textiles’ or ‘electronic paper' (X Duan et al. 2003 Nature 425 274).
“We have made a general conceptual breakthrough by taking nanoelectronics in a new direction: exploiting nanomaterials not for electronic miniaturization, but for better and cheaper electronics over large areas,” said team member Xiangfeng Duan. “We have assembled nanowires into densely packed oriented thin films that can undergo conventional electronic fabrication processes. Since we only use conventional electronic fabrication processes, our technology may lead to the first practical and scalable nanomaterial-enabled electronics.”
To create a nanowire thin-film transistor, the scientists grew p-type silicon nanowires by catalytic chemical vapour deposition. Then they dispersed the wires into solution and used flow-directed alignment to assemble them on the substrate surface at room temperature. This created an oriented monolayer of nanowires with an average interwire spacing of 500-1000 nm, over areas as large as a four-inch wafer. Finally, Duan and colleagues used standard lithography followed by metallization to define source and drain electrodes for the thin-film transistor.
“In amorphous silicon or polycrystalline silicon thin-film transistors, carriers have to travel across multiple grain boundaries, but nanowire thin-film transistors have a perfect conducting channel formed by multiple single-crystal nanowire paths in parallel - like a log bridge,” explained Duan. “This ensures single-crystal carrier paths all the way across the source and drain electrodes, for high carrier mobility. We have demonstrated silicon nanowire thin-film transistors with a carrier mobility of about 100 cm2/Vs - far better than the current macroelectronic technologies of amorphous silicon or organic electronics, which typically have a mobility of less than 1 cm2Vs.”
Moreover, the technique can exploit a broad range of substances as the channel material. As an example, Duan and the team made a thin-film transistor on a silicon substrate from single-crystal nanoribbons of CdS, a material that has useful optical and electrical properties.
The team also made a silicon nanowire thin-film transistor on a plastic substrate made of polyetheretherketone (PEEK). The transistor had a threshold voltage of about 3 V, an on-off ratio above 105, and a sub-threshold swing of 500-800 mV per decade. According to the researchers these values are among the best reported for thin-film transistors on plastic. Slight flexing of the plastic did not significantly affect the device’s properties.
“Our work has the potential to move electronics from single-crystal substrates to glass and plastic substrates, and to integrate macroelectronics, microelectronics - and potentially nanoelectronics - at device level,” said Chunming Niu, director of chemistry at Nanosys.
